Ideal mounting height for EcoSmart Fire wall-mounted bioethanol fireplaces depends on how you want to experience the flame rather than a single fixed measurement. Position the burner at eye level when seated in your primary viewing area, typically 1,200–1,400 mm [47–55 in] from the finished floor, so the flame draws your gaze naturally as you relax.

Viewing angle is the real guide. If you'll stand in front of it, aim higher. If you're watching from a dining table, position lower. The beauty of bioethanol fireplaces is that ventless installation frees you from chimney positioning, ceiling-height constraints, or ventilation paths. Design comfort first, then build clearance into the architecture around it.

Maintain overhead clearance of 1,500 mm [59.1 in] from the flame to any combustible material (ceilings, shelving, curtains). Non-combustible mantels can sit as close as 600 mm [23.6 in]. These aren't rigid rules but sensible margins that protect finishes and ensure safe operation.

Your placement becomes a design choice driven by sightline and room proportion, not a compliance checklist.

Recessed installation of EcoSmart Fire bioethanol fireplaces follows a straightforward three-phase process.

Construct your wall cavity to the specified cut-out dimensions, slide the appliance into the opening so the base sits securely on 50 × 100 mm [2×4 in] framing, then secure it via the mounting hole flanges using a power drill and screwdriver. Remove the transport brackets, complete your wall panelling around the insert, and the fireplace is ready for operation: no venting, no gas line, no electrician required.

The absence of utility connections is what makes recessed installation possible in spaces where traditional fireplaces cannot go: interior feature walls, under-window niches, between built-in cabinetry.

Framing above the appliance must be self-supporting, and the toughened glass windscreen slides into place before the decorative charcoal spreads around the appliance tray. Most installations are completed within an hour.

EcoSmart Fire trade specialists are available to review your design drawings at no cost and provide technical support throughout installation. Compliance with UL 1370 and EN 16647 standards ensures your installation meets all relevant safety requirements.

EcoSmart Fire bioethanol fireplace inserts cost significantly less to install than traditional gas or wood-burning fireplaces because they eliminate structural modifications, gas line installation, and chimney work. Installation focuses on securing the insert in a framework and finishing the surround, a zero-clearance design that removes expensive building work.

The cost advantage comes from simplicity: no venting requirement, no electrical wiring, no combustion air ducts. Installation typically completes in under an hour once the framework is ready, keeping labour costs lower and timelines shorter. Many homeowners invest in professional finishing work, but the fireplace insert itself requires minimal specialist input.

EcoSmart Fire reports up to 70% in cost savings compared to gas fireplaces across the full installation journey. This includes the insert and surrounding build work. The remaining costs reflect design choices: cabinetry finishes, materials, and architectural integration, decisions that would apply regardless of fireplace type.

Once installed, running costs are minimal. A 9-litre fuel refill burns for 8–13 hours depending on heat setting, making it one of the most economical focal point options. Total cost of ownership, including installation and fuel, typically proves competitive with traditional alternatives.

EcoSmart Fire bioethanol fireplaces feature true zero-clearance design. At the back and sides, the appliance frame installs directly into wood or metal stud walls with no spacing required between the unit and surrounding combustible materials.

For mantels and surrounds fitted above or beside the unit, specific vertical clearance distances apply. These differ depending on whether the material is combustible or non-combustible; your model's support page provides the exact dimensions and diagrams for your configuration.

Each model specifies a minimum room volume for adequate ventilation. This is an air quality requirement rather than a physical clearance distance. Your product specifications or installer will confirm the threshold for your room.

Before installation, verify your wall cavity dimensions against the product's cut-out specifications to ensure tolerances align.

EcoSmart’s fireplace inserts are mostly used for new construction when an entirely new fireplace is desired for a given space. They are not designed for the conversion or remodelling of an existing masonry or gas fireplace but could be used if the dimensions align.

To convert an existing fireplace we recommend using our fireplace grates or ethanol burners as noted above.

Ensure that the flue has been closed off and the relevant suppliers have officially detached all connections to utilities.

Unlike gas fireplaces or traditional wood-burning fireplaces, our ethanol fireplace inserts require no venting, no gas line, and no electricity - eliminating the need and cost of three subcontractors. They are simply mounted into the constructed main wall framework with the appropriate opening size for the fireplace insert selected.

EcoSmart Fire’s ethanol fireplace inserts are extremely flexible and can be incorporated at any stage of your interior decorating, renovating or building works.

For detailed specifications please contact us.

No, ethanol fireplace inserts don't require a chimney. The clean-burning chemistry of bioethanol combustion produces only heat, water vapour, and minimal CO2, with no smoke, soot, or harmful gases that would need venting through a flue. This zero-clearance capability means the insert can sit inside your existing fireplace opening with heat retained in the room.

When retrofitting an existing fireplace with an active chimney, simply seal the damper or install a metal plate to block the opening. This prevents warm air escaping up the unused flue and maximises the fireplace's heating efficiency. All EcoSmart Fire bioethanol inserts are UL-listed and EN 16647 certified, meeting international safety standards for clean-burning, unvented operation.

Yes, EcoSmart Fire fireplace inserts are safe to use when installed correctly and operated according to manufacturer guidelines. Inserts are engineered with zero-clearance construction, with combustion containment built directly into the frame, and carry certifications across major markets: UL-listed to UL 1370 (USA), EN 16647 certified (Europe/UK), and compliant with Australian safety mandates.

Every component is engineered for safety. Burners are Grade 304 stainless steel. Glass is toughened, low-iron, and withstands heat exposure. A dedicated filling point, safe shut-off mechanism, and safety markings eliminate handling risk. The combustion system burns cleanly, producing heat, water vapour, and carbon dioxide; each output is managed safely within the minimum room volume requirements for each configuration.

Proper operation requires attention to ventilation. Each model has a minimum room volume requirement (ranging from 40 to 345 m³ depending on configuration) to ensure adequate oxygen and prevent indoor air quality concerns. Installation should follow the trade guidance provided, and the burner tray is mandatory for indoor use. The design reflects 20+ years of research and third-party safety validation. Professional installation is recommended to confirm correct placement and ventilation setup, ensuring reliable performance.

EcoSmart Fire's zero-clearance bioethanol fireplace inserts do not require professional installation. They are designed for confident DIY completion with comprehensive instructions.

The process has three steps: construct a timber-framed cavity to specified dimensions, mount the insert via the included mounting holes, and finish the surround with approved non-combustible materials. No structural modifications or specialist trades are needed.

Many customers choose to involve a qualified builder or interior designer, and this is where professional input earns its value. A tradesperson brings precise placement, tight integration with bespoke cabinetry, and a polished finish that elevates the overall design. If you're building or renovating, they can also coordinate installation timing across other trades on site.

EcoSmart Fire's trade specialists offer a free drawing review to validate your plan before work begins, giving you expert oversight without the cost of full professional installation.

Building permit requirements vary by jurisdiction; confirm local regulations before starting work.

EcoSmart Fire wall-mounted fireplaces are engineered for integration into most wall constructions, though the backing material and clearances matter. Suitable substrates include brick, stone, plastered masonry, fire-rated plasterboard, tile, and concrete. Stud walls work when lined with fire-rated plasterboard and hollow-wall anchors; fabric and wallpaper directly behind the unit must be avoided.

Recessed installations require non-combustible cavity backing, such as vermiculite board, fibre cement, or steel framing lined with fire board, to maintain safe operating temperatures. The Flex Series is purpose-built for architect-led recessed integration and uses specified mounting brackets and spacers to create the necessary air gap for heat distribution.

Installation details vary by model, so the manufacturer's installation manual governs clearances to combustibles and any structural considerations.
