Vertigo 40 Fire Pit Table

Sculpturally striking, perfectly practical

Vertigo 40

A reimagined, contemporary fire pit table with a compact style to suit smaller spaces – think verandahs, patios, balconies, courtyards and apartment or condominium living areas. Makes a statement in both indoor and outdoor settings; a unique, low-set square coffee table for all seasons. Created for pairing with armchairs, loveseats or ottomans, the Vertigo 40 provides a distinctive centrepiece for personalizing your space depending on the occasion and mood.

Shop Now

Accessories

Included

AB8 Efficiency Ring

AB8 Efficient Rings are used to regulate and further stabilise the flame increasing fuel efficiency of the burner.

Jerry Can 5L

The Jerry Can allows for the safe storing/decanting of e-NRG ethanol.

Fire Lighter

This refillable butane lighter supports the safe ignition of the lighting rod. The length of the lighter further enhances the management of the lighting process.

Lighting Rod

The Lighting Rod enables you to safely adjust the slider position of the Burner at any time. It is also used for the ignition and extinguishing procedures.

Bottle Adaptor

The adaptor connects the safety spout from the Jerry Can straight onto the e-NRG bottle making fuelling the fire quicker and easier.

Black Glass Charcoal

The Black Glass Charcoal is made from high-quality tempered glass and has been designed to withstand harsh weather and temperatures of up to 1300ºF/700ºC.

Optional

S380 Fire Screen

Screens help to minimise the impact of wind on the flame and reduce fuel consumption.

R400 Fire Screen

Screens help to minimise the impact of wind on the flame and reduce fuel consumption.

S18 Cover Plate

Transform the burner section of your Ecosmart fire table, easily turning it into a flat, usable coffee table surface.

ST40 All-Season Cover (Low)

These Outdoor Fire Covers help to protect your investment. Made from UV coated Oxford fabric they repel dust, water and other debris for easy maintenance.

Specifications

Application

Indoor or Outdoor

Dimensions

L 1,000 mm [39.4 in]
W 1,000 mm [39.4 in]
H 248 mm [9.8 in]

Weight

63.94 kg [141 lb]

Materials

Fluid™ Concrete Surround; Grade 304 Stainless Steel (Optional Black Ceramic Coating) Burner

Colour

Model

Natural

Graphite

Bone

Burner

Stainless Steel

Black

Bioethanol is suited for both Indoor/Outdoor use; however, additional parts are REQUIRED for indoor use.
The weight includes the burner and black glass charcoal.
Line drawings show model with the Fire Screen installed.

Efficiency

Burner Information
Burner Configuration Compatible with this model	AB8
Volume Capacity How much fuel	8 L 2.1 gal
Thermal Output How much heat it creates	20,433 BTU/h 21.56 MJ/h - 6 kW
Burn Time How long it lasts	7-9 h 8 L [2.1 gal]
Fuel Consumption How much fuel it consumes on MAX	1.1 L/h 0.29 gal/h
Heats on Average How much space it heats	60 m² 646 ft²
Minimum Room Size Required for this burner	116 m³ 4,097 ft³

These values are indicative ONLY and may vary depending on the model purchased,installation, and the fuel composition.
This model complies with existing standards in the USA, Europe, UK and Australia. O-TL listed to UL 1370, EN 16647 BSI Certified and ACCC Safety Mandate compliant for bioethanol burners.
To comply with EN 16647 the Indoor Safety Tray & included AB8 Burner Efficiency Ring must be installed before operating indoors.

Downloads

Model Specifications

PDF

Clearances & Installation Manual

PDF

Installation & Operation Manual - Ethanol Burners

PDF

Videos

How to assemble and operate your AB Series ethanol burner

The product shown in this video is for demonstration purposes only and may not represent the exact model you are viewing.

How to assemble your glass cover plate

The product shown in this video is for demonstration purposes only and may not represent the exact model you are viewing.

How to install the Glass Fire Screen

thumbnail: esf-vertigo-40-fire-table-lounge.jpg

Timeless style

Subtle, sleek and practical. Incorporates a compact base recessed in the centre, giving the visual impression of a floating table.

Practical proportions

Clean-lined square design with a sleek yet sturdy concrete table surface for setting down plates, glasses and cups.

Natural shades

Available in three timeless finishes: Natural, Graphite, and Bone to suit your décor.

Glass fire screen

⁠Pair it with a glass fire screen to stabilise the flame in windy conditions. Vertigo 40 is designed to accommodate two different glass fire screens: a recessed square and a raised round screen.

thumbnail: esf-vertigo-40-fire-table-outdoor-patio-b.jpg

Unobstructed flame

At the heart of the Vertigo 40 is a round-shaped stainless steel burner. Enhance the presentation of the flame with the optional recessed square glass fire screen or raised round screen, offering 360-degree views of the fire. Includes a large burner tray with decorative media to define and delineate the flame.

All-weather materials

Handcrafted using weather-resistant Fluid™ Concrete, an incredibly strong yet relatively lightweight material. The fire pit features a stain and impact-resistant barrier that protects it from environmental weathering - even under extreme conditions and long UV exposure.

Smokeless flame

Enjoy the warmth and beauty of a clean-burning flame without the smoke, soot, or mess associated with a wood fire.

thumbnail: esf-vertigo-40-fire-table-glass-cover-plate.png

Coffee table conversion

An optional glass cover plate allows for easy conversion to a coffee table when the fireplace isn’t in use.

thumbnail: esf-vertigo-40-fire-table-outdoor-patio-d.jpg

Long burn time

Fuelled by environmentally friendly e-NRG bioethanol, Vertigo 40 can burn up to 11 hours straight, depending on installation and weather conditions.

thumbnail: esf-vertigo-50-fire-table-residential-living-room-night.jpg

Available in 
Two Sizes

Vertigo 40 and Vertigo 50 showcase the sleek and contemporary design of our new low-set floating fire table collection - the ultimate in modern living.
